Material: special pv connector PPO material, hardware for copper tin (0.5 Ω contact resistance or less)

Performance: anti-ultraviolet, corrosion resistance, high temperature resistance, high current, low loss (low contact resistance), high life

Rated voltage: 1500V DC (IEC) 800V DC (UL)

Rated current: 50A

Ambient temperature range: - 40 ℃ to 85 ℃ (IEC)

Lock system plug connector: MC4

Protection level: IP67

The connector can be used for 2.5 mm squared, 4mm squared and 6mm cable. Please confirm cable number when buying
